OYAIDE SWO-GX ULTIMO Wall Outlet 24K GOLD

All products for sale are Japan domestic models.

International Shipping directly from Japan.

Product package and manual will be in Japanese language.

Specification is the same as what is sold in Japan. Be sure to check if the same spec works in your environment.

Description

The OYAIDE SWO-GX ULTIMO is an audio wall outlet with phosphor bronze blade receptacles and 24K gold plating. According to OYAIDE, it delivers a warm sound.

Note: This is a grounded (3-pin) wall outlet for use in the United States and Japan. It is not suitable for EU, UK or other socket types. Installation and removal must be done by a licensed electrician.

Blade Receptacles

The blades are deoxidized phosphor bronze with a polished surface and a 20A-compatible structure. They are polished twice (machine barrel polishing, then hand buffing) and finished with 2.0μ 24K gold plating. Holding force is rated at 7 kg or more.

Body and Band

The chassis is high-rigidity PBT resin with 30% glass filler, with a body weight 40% higher than the previous version. Tighter machining keeps the blades and body in close contact to reduce unwanted vibration, and the internal layout was designed using load-distribution simulation. The mounting band is 1.5mm thick 24K gold-plated brass.

Screws and Wiring

All screws are stainless steel. The maximum cable size is 5.5sq, and the blade-to-cable pull strength is over 30 kg. The outlet is completely non-magnetic, and all materials comply with the EU RoHS directive.

Made in Japan

Specification

Model: SWO-GX ULTIMO

Blade: Deoxidized phosphor bronze (surface polished), 20A-compatible structure

Blade Plating: 24K gold plating (2.0μ)

Chassis: PBT resin with 30% glass filler

Mounting Band: 24K gold-plated thick brass

Maximum Cable Size: 5.5sq

Rated Voltage and Current: 125V 15A

PSE certified, Japan domestic model
